xmbWave - Editing the Wave effect

Hi,
I'm back with a minor update to deflating system_plugin_bg.rco.
It now checks for the file size and allows padding to system_plugin_bg.rco files which are less than 40.8 KB.

Deflate_Update.rar

Also a padder for system_plugin_bg.rco files which are less than 41,844 bytes.

Padder.rar

does any1 know how to change the wave speed. the speed it is going now is so slow

Zitat:

---

Zitat von nick101

does any1 know how to change the wave speed. the speed it is going now is so slow

---

Not yet.

Does any one know how to put the waves closer together ?

CrazyEyes the Flames shape was edited right ?? Just making sure.

Zitat:

---

Zitat von SWE_PsYcHo

Does any one know how to put the waves closer together ?

---

Move around the data between 9139 and 24065. I think each section controls one pixel high of detail on the wave effects.

CrazyEyes if possible can u make and edition of Z33's waves black

Zitat:

---

Zitat von The_Kills

AAAAAAH unstable :(

EDIT: to dave

---

Check post 1018 in this thread, It's from my own personal Flash0 ( in other words its what im using now) It's a tad bit more stable.

Zitat:

---

Zitat von Mime

CrazyEyes the Flames shape was edited right ?? Just making sure.

---

Yea, z33 edited 245d - 5965

Zitat:

---

Zitat von saf100792

CrazyEyes if possible can u make and edition of Z33's waves black

---

I'll try later on this evening, but don't count on it.

i wanna make one that shifts colors from like blue to purple to red with all the colors in between... wonder if its possible..

This is what the flame waves look like black, if someone knows another way to turn the waves black let me know, cause this just looks crappy.

http://img530.imageshack.us/img530/9237/screen1ua6.png

Zitat:

---

Zitat von CrazyEyes

This is what the flame waves look like black, if someone knows another way to turn the waves black let me know, cause this just looks crappy.

http://img530.imageshack.us/img530/9237/screen1ua6.png

---

Whoa.. upload RCO

click on the picture

If any one on a mac was wanting to do this i made a applescript and icon-coder for it http://forums.qj.net/f-psp-developme...hlight=xmbWave Also ill try to make a linux version its really easy just go download http://zlib.net/zpipe.c
then make sure you have zlib installed
and run this to compile zpipe (icon-coder)

Code:

---

gcc zpipe.c -lz

---

then rename a.out to zpipe then put it in your /usr/bin folder
navigate to the XMBWave folder and run

Code:

---

rm system_plugin_bg.rco
        rm system_plugin_bg_part2.bin
        cp system_plugin_bg_part1.bin part1.temp
        cp system_plugin_bg_part3.bin part3.temp
        ./zpipe < system_plugin_bg_deflate.bin > system_plugin_bg_part2.bin
        cat system_plugin_bg_part3.bin >> system_plugin_bg_part2.bin
        cat system_plugin_bg_part2.bin >> system_plugin_bg_part1.bin
        cat system_plugin_bg_part1.bin >> system_plugin_bg.rco
        rm system_plugin_bg_part1.bin
        rm system_plugin_bg_part3.bin
        cp part1.temp system_plugin_bg_part1.bin
        cp part3.temp system_plugin_bg_part3.bin
        rm part1.temp
        rm part3.temp

---

and there ya go (works on almost any comp)

For those of you tired of going through all the command prompts here is a very useful program that will allow you to extract the OMG (the part you people are hexing) and replace it in a 2.50 system_plugin_bg.rco

Not to mention it supports just about all the other RCOs in 2.50 ;)

http://zingaburga.freehostia.com/for...tid=167&page=1

Here are a couple variations of the flame wave.

http://img406.imageshack.us/img406/6117/fire2qy1.png
Download

http://img403.imageshack.us/img403/1513/video1oo7.gif
Download

way to go man..

YET ANOTHER Z33 RELEASE!
COMPLETE PACK FROM THE OTHER SITE!

zWavePak.zip

Does anyone particularly z33 want to write up a nice tutorial Because I figured out that tha part in where you said to edit to change the thickness will also change the color. Also it can Change the wave shape. I understand the color completely thats really easy. I really cant add another wave thoug because when i do that it just shows no waves. A nice tut would be very good and the tut should end up making something unique to each person. (Like do something based off their telephone number or something).

Does anyone Know how to contact Z33??

Zitat:

---

Zitat von a_noob

Does anyone Know how to contact Z33??

---

TRY This SITE!

Z33-MaxConsole

Here: Z33's Document (Responsible for the waves) for system_plugin_bg.rco.

Z33's Document

Zitat:

---

Zitat von a_noob

I really cant add another wave thoug because when i do that it just shows no waves.

---

to fix that check the file size of system_plugin_bg.rco, it needs to be 41,844 bytes. If its smaller, open the .rco in your hex editor and add zeros at the end untill you get 41,844 bytes.

Zitat:

---

Zitat von CrazyEyes

to fix that check the file size of system_plugin_bg.rco, it needs to be 41,844 bytes. If its smaller, open the .rco in your hex editor and add zeros at the end untill you get 41,844 bytes.

---

Or use this Padder, It checks the file size and pad the appropriate "00". Don't worry it's fool proof.

FOUND OUT THAT Z33 HAS PACK HIS RELEASE A DIFFERENT WAY.
DEFLATING IS IMPOSSIBLE USING MY SCRIPT!

USE RCOTOOL TO DEFLATE HIS RELEASE, IT'S HIS OWN TOOL.

rcotool.exe Resource (.rco) graphics extractor BY Z33

Zitat:

---

Zitat von nicinico

TRY This SITE!

Z33-MaxConsole

Here: Z33's Document (Responsible for the waves) for system_plugin_bg.rco.

Z33's Document

---

Wow, that documentation explains a lot. Specifically:

"0x4314 bytes of texture data as regular targa imagefile here including padding to 4 byte boundary"

http://img174.imageshack.us/img174/3420/testcrj7.jpg



I feel like a idiot now :Cry:

Atleast now I know an easier way to edit color and shape.

care ta share? :P i have no idea what you are talkin about lol.

Zitat:

---

Zitat von Anger

care ta share? :P i have no idea what you are talkin about lol.

---

Well, the texture as well as the colors are included inside a TGA image file. Knowing this makes editing the waves a whole lot easier (to change color, you can just use a photoshop filter). The image is between offsets 7056 and 24228. Extract this and save it as a .tga .

Also, it seams Z33's wave effects weren't so planned after all.

This is his texture file:
http://img163.imageshack.us/img163/1552/tempsq8.jpg

But go him for documenting the file!:tup:

Zitat:

---

Zitat von Nielkie

Well, the texture as well as the colors are included inside a TGA image file. Knowing this makes editing the waves a whole lot easier (to change color, you can just use a photoshop filter). The image is between offsets 7056 and 24228. Extract this and save it as a .tga .

Also, it seams Z33's wave effects weren't so planned after all.

This is his texture file:
http://img163.imageshack.us/img163/1552/tempsq8.jpg

But go him for documenting the file!:tup:

---

Sounds like I could make a new program for that :p
Want one?

new one from z33


klick on the picture to download this!

http://oms.wmhost.com/angles.jpg

is the file size really that important cause none of the ones i make are exactly the right size.. they all vary a little but they all work like some are 41,838 and i remember another bieng 41,844.. like i said they all work tho

Ok I released tgaWave here's the release thread: http://forums.qj.net/f-psp-developme...ml#post1385138

Here's DEFLATE LATEST release!

DEFLATE_LATEST

The batch script now supports both Vulpix and Z33 system_plugin_bg.rco files.
Read the Readme.txt

YOU MIGHT NEED fc.exe IF YOU'RE USING XP THEN NO PROBLEM!

:(:(:(I don't understand how edit the system_plugin_bg_deflate. tga file :(

Zitat:

---

Zitat von Nielkie

Well, the texture as well as the colors are included inside a TGA image file. Knowing this makes editing the waves a whole lot easier (to change color, you can just use a photoshop filter). The image is between offsets 7056 and 24228. Extract this and save it as a .tga .

Also, it seams Z33's wave effects weren't so planned after all.

This is his texture file:
http://img163.imageshack.us/img163/1552/tempsq8.jpg

But go him for documenting the file!:tup:

---

omg so simple. yeah go him - thats an amazing discovery. now we can have any 'waves' we like :)

Zitat:

---

Zitat von matt13

new one from z33


klick on the picture to download this!

http://oms.wmhost.com/angles.jpg

---

are all four of those the same wave?

no they are all differnt but i don't like how it turns tho

After I inject a new tga, the file's compressed size is too big.
Is there a way bypass the file-size limitation?

Did Z33 Release anything else? Because he either found a way to compress more of the file, or remove a lot of junk. His latest release is half the size of the original, so he must have.


BTW, this is the texture file of his latest release:
http://img359.imageshack.us/img359/7952/z3na4.png

Meh, I am still figuring out how the PSP formats the TGA.

P.S. On the PSP, that wave don't look that great.

I've got ten pics of the ps3 wave (all colors) but tried using tga thing and it didn't work

Sorry, if i'm lazy, but looking through 100 pages isn't easy at all. I have looked through 60 of them. Does anyone know where i can download this wave?

http://i163.photobucket.com/albums/t...xX/screen1.jpg

I remember coming across the site and place for downloading them, but i forgot the site and didn't bookmark it. :Argh: I was in a hurry at the time.

I also remember that there were multiple colors.

If someone could find these, than that would be great.

Thanks in Advance.

u kno thats the stock waves with a blue trim and ps3 bg

o, sorry about that. That one is just a regular blue wave with the ps3 background.:Argh: but that one wasn't the one i was really looking for.

I finally found it. (it isn't really like ps3) :PC:

can someone test this for me? i dont have my psp with me atm

http://www.megaupload.com/?d=7RI84LN6
